cetinkayalartarim · Harvester

NCK-01HM

100 HP
2026
Helezon

Developed by Cetinkayalar Agricultural Solutions, the NCK-01 HM is a robust harvesting solution that combines traditional threshing methods with auger conveyor technology. The machine operates via a direct connection to the tractor's power take-off (PTO) shaft, offering a reliable mechanical alternative to pneumatic systems and ensuring the consistent transfer of grain into bags or trailers, even under challenging working conditions.

NCK-01HM

Specifications

Technical Specifications

Property Value Unit
Country of origin Turkey
Total Length 3850 mm
Total Width 2000 mm
Height Total 2300 mm
Feeding Beater Size 1200 kg
Drum Finger Count 44 pcs
Tire Size 600*16
Total Weight 1450 kg
Beater Cycle rpm 1200 rpm
Required PTO rpm 540 rpm
Tractor Power 20-100 HP
Capacity 2200 kg
Shacking System Helezon
